Multi Color SMD5050 Flexible RGB LED Strip Light 60LEDs/M 12V

TOPLEDVISION PHOTONICS CO LIMITED
  • Certification：FCC, RoHS, CE, TUV Ce, IEC,En62471, Lm-80
  • Power：11-15W
  • Emitting Color：Blue
  • Voltage：12V
  • IP Rating：IP33
  • Size ( L*W*D )：5000*10*1.8mm

Base Info

  • Model NO.：TLV-FS5050Q60W-14.4W
  • Type：Flexible LED Strip LED Rope Light
  • LED Source：Quality SMD5050 RGB
  • LED：99.99% Gold Wire, Red Copper Pad
  • PCB：Double-Sided FPC
  • Color：Red,Green,Blue,Color Change,Color Fade,Mixed Chang
  • Working Voltage：12V,24V DC
  • Power Consumption：14.4W,M
  • LED Luminous：18-22lm,LED
  • Lighting：Waterproof LED Strip Light
  • Usage：KTV,Bar,House,Commercial,Decorative,Kitchen...
  • Working Life：>30, 000hours
  • Warranty：2 Years
  • Packing：5mts,Roll, Color Box Packing or Anti-Static Bag
  • Certificates：TUV Ce, FCC, RoHS, IEC,En62471, Lm-80
  • Transport Package：Inner Box and Carton, 100reels,CTN
  • Specification：SMD5050 RGB LED strip 60LEDs,m
  • Trademark：TOPLEDVISION
  • Origin：Shenzhen, China
  • HS Code：9405409000
  • Production Capacity：100000PCS,Month

Description


Multi Color SMD5050 Flexible RGB LED Strip Light 60LEDs/M 12V
TLV-FS5050Q60RGB-12VItemHigh quality 5050 RGB LED stripLED quantity60LEDs/mPower(watt)14.4W/m maxWorking voltage12V DCColor temperaturePure Red, Pure Green, Pure Blue color change and color fade, mixed color changePCB10mm double sided FPCDimension5000*10*1.8mmIP rateIP20(IP33)/IP65/Nano coating/IP67/IP68Cutting SizeEvery 3LEDs(50mm) / 6LEDs(100mm)Back of stripWith Original 3M adhesive tape ( strong double sided more viscous )Working lifespan>30, 000hrsWarranty2 yearsCertificationTUV CE, FCC, IEC/EN62471Good color temperature consistency and stable quality:
We have long-term and large raw material in stock, so always same LED color temperature and strict production for LED strip to keep the same color and stable quality for every batch. Multi Color SMD5050 Flexible RGB LED Strip Light 60LEDs/M 12V
Features as follow:
1. LED source: 18-22lm/LED high brightness and low decline (less than 3%) after 3000hours working.
2. Modular design: Every 3LEDs or 6LEDs as a module and work independently.
3. Voltage: 12V/24VDC input Voltages can support longer LED strip connection.
4. Working current: 90-95% to keep the lumen efficiency safely
5. FPC size: 10mm width FPC and smaller components, LED stripe is more flexible.
6. Support customized size: You can cut the LED strips into the size you want (support customized length).
7. Dimming support: By manual or IR, be able to adjust the LED stripes brightness.
8. Lifespan: Our LED rope light more than 50000hours working life with 2 years warranty.
9. Easy Installation: 3M tape on the back of strip light and maintenance free.
10. IP rating: Our flexible LED strip light have different IP level be able to install in any indoor/outdoor environments (non-waterproof, waterproof)
11. ≤ 15º C temperature rise.
12.100% aging line test before packing minimizes the possibility of defective products out of the factory.
13. TUV CE, FCC, RoHS and IEC/EN62471 photobiological safety compliant.
Multi Color SMD5050 Flexible RGB LED Strip Light 60LEDs/M 12VService1. Provide free technology support by phone and e-mail2. We provide training to replace the broken part3. Two years guarantee: In guarantee period, we provide the free new part for replacing. Payment50/% deposit by T/T. Balance T/T before shipment. DeliveryApprox 7-10 working days normally ( from receiving the deposit )TransportationBy Air / SeaEffective date30days
We welcome OEM and ODM service, we have professional engineer to design and produce according your requirement.
